Image Sensor

1/2.8" CMOS

Pixel

8MP

Max. Resolution

3840 (H) × 2160 (V)

Electronic Shutter Speed

1/1 s–1/30,000 s

Scanning System

Progressive

Min. Illumination

Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux(IR light on)

Illumination Distance

50 m (164.04 ft) (white light)
150 m (492.13 ft) (IR)

Illuminator On/Off Control

Zoom Prio; Manual; Smart IR; Off

Illuminator Number

2 (IR)
2 (Dual light fusion)

Lens

Focal Length

4.7mm–94 mm

Max. Aperture

F1.6–F3.6

Field of View

H: 51.9°–3.0°; V: 39.7°–2.2°; D: 63.1°–3.7°

Optical Zoom

20×

Focus Control

Auto; semi-auto; manual

Close Focus Distance

0.1 m–1.5 m (0.33 ft–4.92 ft)

Iris Control

Auto; manual

DORI Distance

Detect

Observe

Recognize

Identify

2,500 m (8202.10 ft)

987.5 m (3239.83 ft)

500 m (1640.42 ft)

250 m (820.20 ft)

PTZ

Pan/Tilt Range

Pan: 0° to 360° endless
Tilt: –20° to +90°, auto flip 180°

Manual Control Speed

Pan: 0°/s–300°/s
Tilt: 0°/s–100°/s

Preset Speed

Pan: 0°/s–300°/s
Tilt: 0°/s–100°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Idle Motion

Pattern; Preset; Scan; Tour

PTZ Protocol

DH-SD

Intelligence

Auto Tracking

Yes

Humanoid Detection

Yes

Vehicle Identification

Yes

Active Deterrence

Light Warning

White warning light. They can be configured to flash for 5 to 30 seconds with a high, medium or low frequency.

Sound Warning

Customizable sound alarm

Video

Video Compression

H.264/H.265/H.265+

Streaming Capability

2 streams

Resolution

Main stream:3840*2160@20fps,3072*2048/2592*1944/2560*1440/2304*1296/1080P/720P@30fps,sub-stream:720*480/D1/VGA/640*360@30fps

Video Frame Rate

Main stream:3840*2160@20fps,3072*2048/2592*1944/2560*1440/2304*1296/1080P/720P@30fps,sub-stream:720*480/D1/VGA/640*360@30fps
Sub stream : 720*480/D1/VGA/640*360@30fps

Bit Rate Control

CBR/VBR

Video Bit Rate

H264: 96 kbps–14848 kbps
H265: 38 kbps–8960 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

WDR

Yes

HLC

Yes

White Balance

Auto

Gain Control

Auto; manual

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Image Stabilization

Electronic (EIS)

Digital Zoom

10×

Image Rotation

180°

S/N Ratio

≥55 dB

Audio

Audio Compression

G.711/G711A audio compression standard

Network

Network Port

RJ-45 (10/100 Base-T)

Network Protocol

1*RJ45 10/100M adaptive Ethernet port; Support HTTP/DHCP/NTP/ONVIF/P2P and other network protocols, optional GB28181, RTMP and multiple NVR docking protocols

Interoperability

CGI;SDK;ONVIF (Profile S&G&T)

Streaming Method

Unicast/Multicast

User/Host

20 (total bandwidth: 64 M)

Storage

FTP/SFTP; Micro SD card (512 GB); NAS

Browser

IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions

Management Software

DSS; DMSS

Mobile Client

iOS; Android

Certification

Certifications

CE-EMC: EN 55032; EN 61000-3-3; EN 61000-3-2; EN 50130-4; EN 55035
CE-LVD: EN 62368-1
FCC: 47 CFR FCC Part15, Subpart B, NSI C63.4

Port

Audio Input

1 channel

Audio Output

1 channel

Alarm Linkage

Capture; recording; send email; preset; tour; pattern; alarm digital input; audio; warning light

Alarm Event

Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection

Alarm I/O

2/1

Audio I/O

1/1

Power

Power Supply

12V DC/2.5 A ± 25% (included)
PoE+ (802.3at)

Power Consumption

Basic: 13 W
Max.: 23 W
(illuminator + White warning light + speaker + PTZ working)

Environment

Operating Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Operating Humidity

≤95%

Protection

IP66; TVS 6000 V lightning proof; surge protection; voltage transient protection

Structure

Product Dimensions

325.3 mm × Φ202.0 mm (12.81" × Φ7.95")

Net Weight

1.6 kg

Gross Weight

2.0 kg
