Features:

*A-level monocrystalline silicon 4V/35W(693*295.5mm)

*LiFePO4 Battery 48Ah

*154 pcs SMD3030 Leds.

*CCT: 6500-7500K.

*Lumen Output: 3600lm.

*4MP 4G PTZ Camera.

*Low Power Consumption 4G camera.

*3.6mm fixed lens.

* Support cloud storage，TF card storage（Up to 256G）.

*Two way audio.

*Humanoid Tracking.

*App:EseeCloud.

*Discharge time:4-5 rainly & cloudy days.

*IP65 protection


Specifications:

Model

SSLC3548

Camera

Sensor

1/2.8″, 4.0 megapixel, progressive scan, CMOS

Day/night swtich mode

ICR Infrared filter type

WDR

Digital WDR

DNR

3D DNR

Pan&Tilt

Pan: 0° ~ 263°,0.1°-20°/s

Tilt: 0° ~ 90°,0.1°-10°/s

WDR

120dB

S/N

>56dB

Lens

Lens

3.6mm@F1.6

Iris

Fixed

Field of View (H)

87.6°

Field of View (V)

51.2°

Field of View (D)

96.5°

DORI



DORI Distance

Lens (mm)

Detect  (m)

Observe  (m)

Recognize  (m)

Identify  (m)

3.6

62.1

24.8

12.4

6.2

Video

Video Compression

H.264/H.265



Frame Rate

Main Stream: 4MP (2560*1440), Max 15fps;

Sub Stream:  640*360,Max 25fps;

Video Bit Rate

128 Kbps~16 Mbps

Video Stream

Double streams



Audio

Audio Compression

ACC/G711

Audio Bitrate

64 Kbps

Two-way audio

Support

Storage

Edge Storage

Cloud storage & Max. 256G SD card storage

Network Storage

ANR, NAS(NFS)

4G

4G Bands

FDD:B1/B3/B5/B8，TDD:B34/B38/B39/B40/B41

Solar Street Light

Solar Panel

A-level monocrystalline silicon 4V/35W(693*295.5mm)

Battery

 LiFePO4 48Ah 5V

Number of lamp chip

 154 pcs SMD3030

Material

AL6063+Teijin PC

Lamp size

700*30*145mm

Pole size

 φ76mm



Discharge time

4-5 rainly & cloudy days

CCT

6500-7500K

Installation Height

4m

Lumen Output

4500lm

IP Rank

IP65



General

Carton Dimensions (L × W × H)

720× 200 × 340mm, (4pcs/Carton)

Gross Weight

19kg (41.89lb)

Working Environment

-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)

Strorage Environment

-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
