Features:

• High quality image with 12MP,1/2.3’CMOS sensor

• Max 4000*3000 resolution

• Ultra265, H.265, H.264, MJPEG

• Ultra wide angle lens 2.8mm.

• Embedded infrared light, up to 30m IR distance.

• Multiple decoding modes, supports software and hardware modes, provides interactive dynamic view

• Heatmap: Working with management platform, the data of moving objects is counted in real time on an intuitive color map

• Built-in microphone & speaker, two-way talk supported

• Supports 256 G Micro SD card

• IK10 vandal resistant

• IP67 protection


Specification:


IP1201B701
Camera
Sensor1/2.3", 12.0 megapixel, progressive scan, CMOS
Minimum IlluminationColour: 0.03Lux (F2.0, AGC ON)
0Lux with IR
Day / NightIR-cut filter with auto switch (ICR)
ShutterAuto/Manual, shutter time: 1 ~ 1/100000s
WDRDWDR
S/N>52dB
Lens
Lens type2.8mm@F1.0
Field of View100°
Illuminator
IR RangeUp to 30m IR range
wavelength850nm
IR On/Off ControlAuto/Manual
Video
CompressionUltra265, H.265, H.264, MJPEG
H.264 code profileBaseline profile, Main Profile, High Profile
Main Stream12MP(4000*3000)@25fps,3840*2160@30fps,3072*2048@30fps,2592*1944@30fps,2560*1440@60fps,2304*1296@60fps
Sub Stream720*480@30fps,640*360@30fps
Video Bit Rate128 Kbps~16 Mbps
U-codeSupport
OSDUp to 8 OSDs
Privacy MaskUp to 4 areas
ROIUp to 8 areas
Video streamTriple streams
White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction2D/3D DNR
Smart IRSupport
FlipNormal/Flip Vertical/ Flip Horizontal/180°
DewarpingN/A
HLCN/A
BLCSupport
Intelligent
Smart intrusion preventionSupport for cross border detection, entering and exiting regions, and regional intrusion
Statistical AnalysisNo
Events
Basic DetectionCapable of classifying, detecting, and defending motor vehicles, non motor vehicles, and pedestrians
General FunctionWatermark, IP Address Filtering, Tampering Alarm ,Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio CompressionG.711U, G.711A
Audio Bitrate64 Kbps
Two-way audioSupport
SuppressionSupport
Sampling Rate8KHZ
Storage
Edge StorageMicro SD, up to 256GB
Network StorageANR, NAS(NFS)
Network
ProtocolsHTTP/RTSP/DHCP/NTP/ONVIF/P2P
Compatible IntegrationONVIF (Profile S, Profile G, Profile T), API,SDK
User/HostUp to 32 users. 3 user levels: administrator, common user and operator
ClientLMS
Web BrowserPlug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Interface
Built-in MicTwo Mics
Built-in SpeakerSupport
Network1 RJ45 10M/100M Base-TX Auto-adaptive Ethernet
Certifications
EMCCE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020)
FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
SafetyCE LVD (EN 62368-1:2014+A11:2017)
CB (IEC 62368-1:2014)
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
EnvironmentCE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
ProtectionIP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
IK10 (IEC 62262:2002)
General
PowerDC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 12W
Dimensions (Ø x H)Φ149 x 55mm (Φ5.9” x 2.2”)
Weight805g
MaterialMetal
Working Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH
Strorage Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH
surge protection4kv
Reset ButtonSupport
