Camera Features:

1. High quality imaging with 4MP resolution

2. 2.4g&5g Wifi connection.

3.Excellent low-light performance with powered-by Dark Fighter technology

4.One image that presents all the scenes covered by the camera

5.Clear imaging against strong back light due to 120 dB true WDR technology

6.Focus on human targets classification based on deep learning

7.Active strobe light and audio alarm to warn intruders off

8.Provide real-time security via built-in two-way audio

9.Water and dust resistant (IP65)

10.Build in TF Card Slot supports max 512GB



Specification:

Camera

Image Sensor

2 × 1/2.8" Progressive Scan CMOS

Max. Resolution

3840*1080

Min. Illumination

Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter Time

1/3 s to 1/100,000 s

Day & Night

IR cut filter

Angle Adjustment

Pan: -30° to 30°, tilt: -75° to 75°

Lens

Lens Type

Fixed focal lens, dual lens, 3.6 mm

Focal Length & FOV

3.6mm, horizontal FOV: 155°, vertical FOV: 60°

Lens Mount

M12

Iris Type

Fixed

Aperture

F1.6

DORI

DORI

3.6 mm, D: 42 m, O: 16.5 m, R: 8 m, I: 4 m

Illuminator

Supplement Light Type

IR

Supplement Light Range

Up to 40 m

Smart Supplement Light

Yes

IR Wavelength

850 nm

Video

Main Stream

50 Hz: 20 fps (3840*1080)

60 Hz: 20 fps (3840*1080)

Sub-Stream

50 Hz: 20 fps (1280*360)

60 Hz: 20 fps (1200*360)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG

Video Bit Rate

32 Kbps to 16 Mbps

H.264 Type

Baseline Profile, Main Profile, High Profile

H.265 Type

Main Profile

Bit Rate Control

CBR, VBR

Region of Interest (ROI)

1 fixed region(s) for main stream

Scalable Video Coding (SVC)

H.264 and H.265 encoding

Audio

Audio Type

Mono sound

Environment Noise Filtering

Yes

Audio Sampling Rate

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Audio Bit Rate

64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

Network

Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface,RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)

Simultaneous Live View

Up to 6 channels

API

Open Network Video Interface Profile S, Profile T, Profile G,ISAPI, SDK

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP,

IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, Websocket,

Websockets

Network Storage

NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR),

Together with high-end Hikvision memory card, memory card encryption and health

detection are supported.

User/Host

Up to 32 users

3 user levels: administrator, operator, and user

Client

LMS,iVMS-4200, Hik-Connect, Hik-Central，Guarding version

Web Browser

Plug-in required live view: IE 10, IE11,

Plug-in free live view: Chrome 57.0+, Firefox 52.0+,

Local service: Chrome 57.0+, Firefox 52.0+


Image Parameters Switch

Yes

Image Settings

Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client

software or web browser

Day/Night Switch

Day, Night, Auto, Schedule

Wide Dynamic Range (WDR)

120 dB

SNR

≥ 52 dB

Image Enhancement

BLC, HLC, 3D DNR

Interface

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB

Built-in Microphone

Yes

Built-in Speaker

Max. power consumption: 1.2 W, max. sound pressure level: 10 cm: 95 dB

Audio

1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7

KΩ, interface type: non-equilibrium,

1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output

impedance: 100 Ω, interface type: non-equilibrium

Alarm

1 input, 1 output (max. 24 VDC, 1 A)

Reset Key

Yes

Event

Basic Event

Motion detection (support alarm triggering by specified target types human, alarm input and output, flashing alarm light output, audible alarm output,

exception

Smart Event

Line crossing detection, intrusion detection, region entrance detection, region exiting

detection (support alarm triggered by specified target types (human),

scene change detection

Linkage

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning, white light flashing

General

Power

12 VDC ± 25%, 0.88 A, max. 10.5 W, Ø 5.5 mm coaxial power plug,

PoE: 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W

Material

Front cover: metal, body: metal, bracket: metal

Dimension

118.6 mm × 105.1 mm × 306.5 mm (4.7" × 4.1" × 12.1")

Package Dimension

405 mm × 190 mm × 180 mm (16" × 7.5" × 7.1")

Weight

Approx. 1400 g (3.1 lb.)

With Package Weight

Approx. 2100 g (4.6 lb.)

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating

Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Language

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function

Heartbeat, anti-banding, mirror, password protection, password reset via email

Flashing Light

Yes

Approval

EMC

FCC: 47 CFR Part 15, Subpart B,

CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN

50130-4: 2011 +A1: 2014,

RCM: AS/NZS CISPR 32: 2015,

IC: ICES-003: Issue 7

Safety

UL: UL 62368-1,

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017

Environment

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006

Protection

IP67: IEC 60529-2013
